Place of Origin:
Shaanxi, Xian
Фирменное наименование:
SHACMAN
Сертификация:
ISO 9001/CCC
Model Number:
X3000
| Model | SX41854V361C |
|---|---|
| Drive type | 4x2 |
| Weight | Gross Vehicle Weight ≤45 |
| Dimensions | Wheelbase/(mm) 3600 |
| Performance | Maximum speed/(km/h) 60~70/100 Ground clearance >314 |
| Engine | Brand: CUMMINS Model: ISME420 30 Power/(kw/HP): 316kw / 420Hp Maximum torque / (N.M)/rpm: 2050 N*M Displacement/(L): 11.596 L Emission standard: Euro III |
| Gear box | Brand: FAST Model: 12JSD200T-B+QH50 |
| Clutch | Type: φ430 Diaphragm spring clutch |
| Cooling | Type: Domestic heat sink |
| Air inlet | Type: Ordinary air filter |
| Brakes | Type: Drum brake Service brake: Double circuit air brake Park brake: Rear wheel spring brake Auxiliary brake: WEVB engine exhaust brake |
| Steering | Type: ZF8098 technology, circulating ball steering machine |
| Chassis | Type: Parallel trapezoidal frame with variable section Dimensions/(mm): (940-850)×300(single 8) |
| Suspension | Front: Multi-leaf springs front and rear, dual shock absorbers for rear suspension Rear: Multi-leaf springs front and rear, dual shock absorbers for rear suspension |
| Axles | Brand: HANDE Front axle: 7.5T front axle MAN technology Rear axle: 13T MAN Double Reduction Drive axle with inter helix differential and differential lock, bridge speed ratio: 3.364 |
| Tires | Type: 315/80R22.5 |
| Fuel tank | Tank capacity/(L): 600+300L Aluminum tank |
| Electrics | Type: 24V Battery: 180Ah Maintenance-free battery |
| Cab | Type: SHACMAN X3000 double sleeper with A/C Equipment: X3000 extended high-roof cab with top side deflector, air main seat, four-point air suspension, electric electrically heated mirrors, electronically controlled automatic temperature-controlled air conditioning, electric window crank, electric flip, fiberglass bumper, common air filter, common exhaust, tank protection grille, JOST50 saddle, front and rear stabilizer bars, imported steering, three-section integral fenders with anti-splash, 180Ah maintenance-free batteries Central locking (dual remote control) |
